| Loại máy |
Máy ảnh kỹ thuật số có thể thay ống kính |
| Sử dụng thẻ |
SD Memory Card, SDHC Memory Card, SDXC Memory Card (Compatible with UHS-I standard SDHC / SDXC Memory Cards) |
| Kích thước cảm biến |
17.3 x 13.0 mm (in 4:3 aspect ratio) |
| Ngàm ống kính |
Micro Four Thirds mount |
| Loại cảm biến |
Live MOS Sensor |
| Tổng điểm phân giải |
16.68 Megapixels |
| Độ phân giải hiệu dụng |
16.0 Megapixels |
| Lọc màu |
Bộ lọc màu nguyên thủy |
| Khử bụi cảm biến |
Sóng siêu thanh |
| Định dạng |
|
| Ảnh: |
JPEG (DCF, Exif 2.3), RAW MPO (When attaching 3D lens in Micro Four Thirds System standard) |
| Phim: |
AVCHD (Audio format: Dolby Digital 2ch) / MP4 (Audio format AAC 2ch) |
| Cỡ ảnh |
4:3, 3:2, 16:9, 1:1 |
| Chất lượng |
RAW, RAW+Fine, RAW+Standard, Fine, Standard MPO+Fine, MPO+Standard (When attaching 3D lens in Micro Four Thirds System standard) |
| Color Space |
sRGB, Adobe RGB |
| Dung lượng tập tin |
|
| Ảnh |
[4:3] 4,592 x 3,448 (L) [16M], 3,232 x 2,424 (M) [8M], 2,272 x 1,704 (S) [4M], 1,824 x 1,368 (When attaching 3D lens in Micro Four Thirds System standard)
[3:2] 4,576 x 3,056 (L) [14M], 3,232 x 2,160 (M) [7M], 2,272 x 1,520 (S) [3.5M], 1,824 x 1,216 (When attaching 3D lens in Micro Four Thirds System standard)
[16:9] 4,576 x 2,576 (L) [11.5M], 3,232 x 1,824(M) [6M], 1,920 x 1,080 (S) [2M], 1,824 x 1,024 (When attaching 3D lens in Micro Four Thirds System standard)
[1:1] 3,424 x 3,424 (L) [11.5M], 2,416 x 2,416 (M) [6M], 1,712 x 1,712 (S) [3M], 1,712 x 1,712 (When attaching 3D lens in Micro Four Thirds System standard) |
| Phim |
MP4: NTSC: [Full HD] 1,920 x 1,080, 30fps (sensor output is 30p) (Approx. 20Mbps)
MP4: NTSC: [HD] 1,280 x 720, 30fps (sensor output is 30p) (Approx. 10Mbps)
MP4: NTSC: [VGA] 640 x 480, 30fps (sensor output is 30p) (Approx. 4Mbps)
MP4: PAL: [Full HD] 1,920 x 1,080, 25fps (sensor output is 25p) (Approx. 20Mbps)
MP4: PAL: [HD] 1,280 x 720, 25fps (sensor output is 25p) (Approx. 10Mbps)
MP4: PAL: [VGA] 640 x 480, 25fps (sensor output is 25p) (Approx. 4Mbps)
AVCHD: NTSC: [Full HD] 1,920 x 1,080, 60i (sensor output is 30p) (FSH: 17 Mbps)
AVCHD: NTSC: [HD] 1,280 x 720, 60p (sensor output is 30p) (SH: 17 Mbps)
AVCHD: PAL: [Full HD] 1,920 x 1,080, 50i (sensor output is 25p) (FSH: 17 Mbps)
AVCHD: PAL: [HD] 1,280 x 720, 50p (sensor output is 25p) (SH: 17 Mbps) |
| Continuous Recordable Time (Motion Image)* |
AVCHD with picture quality set to [FSH]: Approx. 130 min with H-FS014042 / Approx. 140 min with H-PS14042 / Approx. 150 min with H-H014 |
| Thời gian ghi hình liên tục (Motion Images)* |
AVCHD with picture quality set to [FSH]: Approx. 65 min with H-FS014042 / Approx. 70 min with H-PS14042 / Approx. 75 min with H-H014 |
| Loại |
Contrast AF system |
| Các chế độ lấy nét |
AFS (Single) / AFF (Flexible) / AFC (Continuous) / MF |
| Chế độ lấy nét tự động |
Face detection / AF Tracking / 23-area-focusing / 1-area-focusing / Pinpoint Touch (1-area-focusing in Face detection / AF Tracking / Multi-area-focusing / 1-area-focusing / Pinpoint) |
| AF Detective Range |
EV 0 - 18 (ISO100 equivalent) |
| Đèn hổ trợ lấy nét |
YES |
| Khóa AF |
Set the Fn button in custom menu to AF/AE lock or shutter button halfway pressed in AFS mode |
| Others |
Quick AF, Continuous AF (during motion image recording), AF+MF, Touch shutter, Touch MF Assist |
| Hệ thống đo sáng |
144-zone multi-pattern sensing system |
| Chế độ đo sáng |
Intelligent Multiple / Center Weighted / Spot |
| Khoảng đo sáng |
EV 0 - 18 (F2.0 lens, ISO100 equivalent) |
| Chế độ phơi sáng |
Program AE / Aperture Priority AE / Shutter Priority AE / Manual / Auto |
| Độ nhạy ISO |
Auto / Intelligent ISO / 160 / 200 / 400 / 800 / 1600 / 3200 / 6400 / 12800 (Changeable to 1/3 EV step) |
| Bù trừ phơi sáng |
1/3 EV Step, ±5 EV |
| Khóa phơi sáng AE |
Set the Fn button in custom menu to AF/AE lock |
| Chụp AE Bracket |
3, 5, 7 frames, in 1/3, 2/3 or 1 EV Step, ±3 EV |
| Cân bằng trắng |
Auto / Daylight / Cloudy / Shade / Incandescent / Flash / White Set 1, 2 / Color temperature setting |
| Điều chỉnh cân bằng trắng |
Blue/amber bias, Magenta/green bias |
| Nhiệt độ màu |
2,500 K - 10,000 K in 100 K |
| Bracket Cân bằng trắng |
3 exposures in blue/amber axis or in magenta/green axis |
| Loại |
Focal-plane shutter |
| Tốc độ màn trập |
Still Images: 1/4,000 - 60 and Bulb (up to approx. 120 seconds)
Motion Image: 1/16,000 - 1/30 (NTSC), 1/16,000 - 1/25 (PAL) |
| Chụp hẹn giờ |
10 sec, 3 images / 2 sec / 10 sec |
| Remote Control |
Remote control with bulb function by DMW-RSL1 (Optional) |
| Ảnh |
Portrait / Soft Skin / Scenery / Architecture / Sports / Peripheral Defocus / Flower / Food / Objects / Night Portrait / Night Scenery / Illuminations / Baby 1, 2 / Pet / Party / Sunset |
| Phim |
Portrait / Soft Skin / Scenery / Architecture / Sports / Flower / Food / Objects / Low-light / Party / Sunset (Activated by selecting Still Image SCN mode then pressing Video Button. Still Image SCN modes without corresponding Video SCN mode is recorded in mode suitable for the recording situation.) |
| Creative Control |
(Still image & Motion image) Expressive / Retro / High Key / Low Key / Sepia / High Dynamic / Toy Effect / Miniature Effect |
| Tốc độ chụp liên tục |
SH: 20 frames/sec, H: 4.2 frames/sec (When AFS mode), M: 3 frames/sec (with Live View), L: 2 frames/sec (with Live View) |
| Số lượng ảnh có thể chụp liên tiếp |
9 images (when there are RAW files with the particular speed) Unlimited consecutive shooting (when there are no RAW files) (depending on memory card size, battery power, picture size, and compression) |
| Loại |
TTL Built-in-Flash, GN7.6 equivalent (ISO160 • m), Built-in Pop-up |
| Chế độ Flash |
Auto, Auto / Red-eye Reduction, Forced On, Forced On / Red-eye Reduction, Slow Sync., Slow Sync. / Red-eye Reduction, Forced Off |
| Tốc độ đồng bộ |
Less than 1/160 second |
| Flash Output Adjustment |
1/3 EV Step, ± 2 EV |
| Flash Synchronization |
1st Curtain Sync., 2nd Curtain Sync. |
| Hot Shoe |
TTL Auto with FL220 / FL360 / FL500 (Optional) |
| Loại |
TFT LCD with Touch panel |
| Kích thước màn hình |
3.0 inch (7.5 cm) / 3:2 Aspect / Wide-viewing angle |
| Phân giải |
460,000 dots |
| Trường nhìn |
Approx. 100% |
| Điều chỉnh màn hình |
Brightness (7 levels), Contrast and Saturation (7 levels), Red tint (7 levels), Blue tint (7 levels) |
| Live View Functions |
Guide Lines (3 patterns) |
| Additional Zoom Operation |
Touch Zoom (when use power zoom lenses*) *H-PS14042 lens and H-PS45175 lens |
| Digital Zoom |
2x, 4x |
| Still image |
Max. 2x (Not effective with L size recording. Magnification ratio depends on the recording pixels and aspect ratio.) |
| Motion image |
Max. 4.8x (Magnification ratio depends on the recording quality and aspect ratio.) |
| LEVEL GAUGE |
Yes (Built-in 3 shaft accelerometer sensor) |
| DIRECTION DETECTION FUNCTION |
Yes |
| Fn1, Fn2, Fn3*, Fn4* *Fn3 and Fn4 are Touch icons on LCD monitor. |
One Push AE / Preview / Level Gauge / Focus Area Set / Photo Style / Aspect Ratio / Picture Size / Quality / Metering Mode / Flash / Flash Adjust. / I. Resolution / I. Dynamic / EX. Tele Conv. / Digital Zoom / Stabilizer / Sensitivity / White Balance / AF Mode / Drive Mode / Motion Pic. Set / Picture Mode / Histogram / Guide Line / Rec Area |
| C1, C2-1/2/3 |
Yes (Registering personal menu settings) |
| Chế độ Xem lại |
Normal playback, 30-thumbnail display, 12-thumbnail display, Calendar display, Zoomed playback (Max. 16x), Slideshow (duration & effect is selectable), Playback Mode (Normal / Picture / Video / 3D Play / Category / Favorite), Title Edit, Text Stamp, Video Divide, Resize, Cropping, Aspect Conversion, Rotate, Rotate Display, Favorite, Print Set, Protect, Face Recognition Edit |
| Bảo vệ |
Single / Multi, Single in Burst Group / Multi in Burst Group, Cancel |
| Xóa |
Single / Multi / All / Except Favorite |
| In trực tiếp |
PictBridge compatible (Print size, Layout and Date settings are selectable) |
| USB |
USB 2.0 High Speed |
| HDMI |
mini HDMI TypeC
Video: Auto / 1080i / 720p / 480p (576p in PAL system)
Audio: Linear PCM |
| Audio Video Output |
Monaural Type, NTSC / PAL, NTSC only for North America *Check the website of the Panasonic sales company in your country or region for details on the products that are available in your market. |
| Remote |
Remote socket |
| Microphone |
Stereo, Wind-cut: Off / Auto Microphone level adjustable: Lv1 / Lv2 / Lv3 / Lv4 |
| Speaker |
Monaural |
| Ngôn ngữ giao diện |
English, German, French, Italian, Spanish, Polish, Czech, Hungarian, Russian, Chinese (Traditional), Chinese (Simplified), Dutch, Thai, Korean, Turkish, Portuguese, Arabic, Persian, Japanese, Swedish, Danish, Finnish, Greek, Vietnamese *Check the website of the Panasonic sales company in your country or region for details on the OSD languages on the products that are available in your market. |
| Loại Pin |
Li-ion Battery Pack (7.2V, 1,010mAh) (Included) Battery Charger |
| Battery Life (CIPA Standard)** |
Approx. 300 images with H-FS014042
Approx. 310 images with H-PS14042
Approx. 340 images with H-H014 |
| Kích thước (Rộng x cao x Dày) |
116.3 x 67.8 x 39.4 mm / 4.58 x 2.67 x 1.55 inch (excluding protrusions) |
| Trọng lượng |
Approx. 318g / 11.22 oz (SD card, Battery, Body)
Approx. 272g / 9.59 oz (Body only)
Approx. 373g / 13.16 oz (SD card, Battery, H-H014 lens included）
Approx. 413g / 14.59 oz (SD card, Battery, H-PS14042 lens included)
Approx. 483g / 17.04 oz (SD card, Battery, H-FS014042 lens included) |
| Nhiệt độ hoạt động |
0 °C to 40 °C (32 °F to 104 °F) |
| Độ ẩm hoạt động |
10%RH to 80%RH |
| Software |
PHOTOfunSTUDIO 7.0 HD Edition, SILKYPIX® Developer Studio 3.1 SE, LoiLoScope (trial version), USB Driver |
