| Loại máy |
Máy ảnh kỹ thuật số có thể thay ống kính |
| Sử dụng thẻ |
SD Memory Card, SDHC Memory Card, SDXC Memory Card |
| Kích thước cảm biến |
17.3 x 13.0 mm (in 4:3 aspect ratio) |
| Ngàm ống kính |
Micro Four Thirds mount |
| Loại cảm biến |
Live MOS Sensor |
| Tổng điểm phân giải |
13.06 Megapixels |
| Độ phân giải hiệu dụng |
12.10 Megapixels |
| Lọc màu |
Primary color filter |
| Khử bụi cảm biến |
Sóng siêu thanh |
| Định dạng |
|
| Ảnh |
JPEG (DCF, Exif 2.3), RAW |
| Phim |
MPO (When attaching 3D lens in Micro Four Thirds System standard) |
| Cỡ ảnh |
4:3, 3:2, 16:9, 1:1 |
| Chất lượng |
RAW, RAW+Fine, RAW+Standard, Fine, Standard MPO+Fine, MPO+Standard (When attaching 3D lens in Micro Four Thirds System standard) |
| Color Space |
sRGB, Adobe RGB |
| Dung lượng tập tin |
|
| Ảnh |
[4:3] 4,000 x 3,000 (L), 2,816 x 2,112 (M), 2,048 x 1,536 (S), 1,600 x 1,200 (When attaching 3D lens in Micro Four Thirds System standard)
[3:2] 4,000 x 2,672 (L), 2,816 x 1,880 (M), 2,048 x 1,360 (S), 1,600 x 1,064 (When attaching 3D lens in Micro Four Thirds System standard)
[16:9] 4,000 x 2,248 (L), 2,816 x 1,584 (M), 1,920 x 1,080 (S), 1,600 x 904 (When attaching 3D lens in Micro Four Thirds System standard)
[1:1] 2,992 x 2,992 (L), 2,112 x 2,112 (M), 1,504 x 1,504 (S), 1,440 x 1,440 (When attaching 3D lens in Micro Four Thirds System standard) |
| PhimEG |
Motion JPEG [4:3] VGA: 640 x 480, 30 fps / QVGA: 320 x 240, 30 fps
Motion JPEG [HD] 1,280 x 720, 30 fps |
| AVCHD |
NTSC [Full HD] 1,920 x 1,080, 60i (sensor output is 30p) (FSH: 17 Mbps)
NTSC [HD] 1,280 x 720, 60p (sensor output is 30p) (SH: 17 Mbps)
PAL [Full HD] 1,920 x 1,080, 50i (sensor output is 25p) (FSH: 17 Mbps)
PAL [HD] 1,280 x 720, 50p (sensor output is 25p) (SH: 17 Mbps) |
| Thời gian ghi hình liên tục (Motion Images)* |
AVCHD with picture quality set to [FSH]: Xấp xỉ 130 min with H-FS014042 / Xấp xỉ 140 min with H-PS14042 / Xấp xỉ 150 min with H-H014 |
| Thời gian ghi hình thực tế (Motion Image)* |
AVCHD with picture quality set to [FSH]: Xấp xỉ 65 min with H-FS014042 / Xấp xỉ 70 min with H-PS14042 / Xấp xỉ 75 min with H-H014 |
| Loại |
Contrast AF system |
| Các chế độ lấy nét |
AFS / AFC / MF |
| Chế độ lấy nét tự động |
Face detection / AF Tracking / 23-area-focusing / 1-area-focusing / Pinpoint
EV 0 - 18 (ISO100 equivalent) |
| Đèn hỗ trợ lấy nét |
Có |
| AF Lock |
Set the Fn button in custom menu to AF/AE lock |
| Others |
Touch shutter, Quick AF, Continuous AF (during motion image recording), AF+MF, Touch MF Assist |
| Hệ thống đo sáng |
144-zone multi-pattern sensing system |
| Chế độ đo sáng |
Intelligent Multiple / Center Weighted / Spot |
| Khoảng đo sáng |
EV 0 - 18 (F2.0 lens, ISO100 equivalent) |
| Chế độ phơi sáng |
Program AE / Aperture Priority AE / Shutter Priority AE / Manual |
| Độ nhạy ISO |
Auto / Intelligent ISO / 160 / 200 / 400 / 800 / 1600 / 3200 / 6400 |
| Bù trừ phơi sáng |
1/3 EV Step, ±3 EV |
| Khóa phơi sáng AE |
Set the Fn button in custom menu to AF/AE lock |
| Chụp AE Bracket |
3, 5 frame, in 1/3 or 2/3 EV Step, ±4/3 EV |
| Cân bằng trắng |
Auto / Daylight / Cloudy / Shade / Incandescent / Flash / White Set 1, 2 / Color temperature setting / Portrait / Beauty Skin / Sport / Flower / Collection / Baby / Pet / Defocus Control |
| Điều chỉnh cân bằng trắng |
Blue/amber bias, Magenta/green bias |
| Nhiệt độ màu |
2,500 K - 10,000 K in 100 K |
| Bracket Cân bằng trắng |
3 exposures in blue/amber axis or in magenta/green axis |
| Loại |
Focal-plane shutter |
| Tốc độ màn trập |
Still Images: 1/4,000 - 60
Motion Image: 1/16,000 - 1/30 (NTSC), 1/16,000 - 1/25 (PAL) |
| Chụp hẹn giờ |
10 sec, 3 images / 2 sec / 10 sec |
| Ảnh |
Portrait / Soft Skin / Scenery / Architecture / Sports / Peripheral Defocus / Flower / Food / Objects / Night Portrait / Night Scenery / Illuminations / Baby 1, 2 / Pet / Party / Sunset |
| Phim |
Portrait / Soft Skin / Scenery / Architecture / Sports / Flower / Food / Objects / Low-light / Party / Sunset (Activated by selecting Still Image SCN mode then pressing Video Button. Still Image SCN modes without corresponding Video SCN mode is recorded in mode suitable for the recording situation.) |
| Creative Control |
(Still Image & Motion Image) Expressive / Retro / High Key / Sepia / High Dynamic / Miniature |
| Tốc độ chụp liên tục |
H: 3.8 frames/sec, M: 2.8 frames/sec (with Live View), L: 2 frames/sec (with Live View) |
| Số lượng ảnh có thể chụp liên tiếp |
7 images (when there are RAW files with the particular speed)/ Unlimited consecutive shooting (when there are no RAW files)/ (depending on memory card size, battery power, picture size, and compression) |
| Loại |
TTL Built-in-Flash, GN6.3 equivalent (ISO160 • m), Built-in Pop-up |
| Chế độ Flash |
Auto, Auto / Red-eye Reduction, Forced On, Forced On / Red-eye Reduction, Slow Sync., Slow Sync. / Red-eye Reduction, Forced Off |
| Tốc độ đồng bộ |
Less than 1/160 second |
| Đồng bộ Flash |
1st Curtain Sync. |
| Loại |
TFT LCD with Touch panel |
| Kích thước màn hình |
3.0 inch (7.5 cm) / 3:2 Aspect / Wide-viewing angle |
| Phân giải |
460,000 dots |
| Trường nhìn |
Xấp xỉ 100% |
| Điều chỉnh màn hình |
Brightness (7 levels), Contrast and Saturation (7 levels), Red tint (7 levels), Blue tint (7 levels) |
| Zoom kỹ thuật |
2x, 4x |
| Extra Tele Conversion |
Still Image: Max. 2x (Not effective with L size recording. Magnification ratio depends on the recording pixels and aspect ratio.)
Motion Image: 3.1x (SH/H in AVCHD and HD/WVGA in Motion JPEG)/ 4.2x (VGA/QVGA in Motion JPEG) |
| Other Functions |
Guide Lines (3 patterns)/ Real-time Histogram |
| Chế độ Xem lại |
Normal playback, 30-thumbnail display, 12-thumbnail display, Calendar display, Zoomed playback (Max. 16x), Slideshow (duration & effect is selectable), Playback Mode (Normal / Picture / AVCHD / Motion JPEG / 3D Play / Category / Favorite), Title Edit, Text Stamp, Video Divide, Resize, Cropping, Aspect Conversion, Rotate, Rotate Display, Favorite, Print Set, Protect, Face Recognition Edit |
| Bảo vệ |
Single / Multi, Single in Burst Group / Multi in Burst Group, Cancel |
| Xóa |
Single / Multi / All / Except Favorite |
| In trực tiếp |
PictBridge compatible (Print size, Layout and Date settings are selectable) |
| USB |
USB 2.0 High Speed |
| HDMI |
mini HDMI TypeC
Video: Auto / 1080i / 720p / 480p (576p in PAL system)
Audio: Linear PCM |
| Audio Video Output |
Monaural Type, NTSC / PAL, NTSC only for North America *Check the website of the Panasonic sales company in your country or region for details on the products that are available in your market. |
| Microphone |
Monaural, Wind-cut: Off / Low / Standard / High
Mic level adjustable: Lv1 / Lv2 / Lv3 / Lv4 |
| Cổng ra Audio Video |
Monaural |
| Ngôn ngữ giao diện |
English, German, French, Italian, Spanish, Polish, Czech, Hungarian, Russian, Chinese (Traditional), Chinese (Simplified), Dutch, Thai, Korean, Turkish, Portuguese, Arabic, Persian, Japanese, Swedish, Danish, Finnish, Greek, Vietnamese *Check the website of the Panasonic sales company in your country or region for details on the OSD languages on the products that are available in your market. |
| Loại Pin |
Li-ion Battery Pack (7.2V, 940mAh) (Included)
Battery Charger |
| Battery Life (CIPA Standard)** |
Xấp xỉ 320 images with H-FS014042
Xấp xỉ 330 images with H-PS14042
Xấp xỉ 340 images with H-H014 |
| Trọng lượng |
Xấp xỉ 264 g / 9.31 oz (SD card, Battery, Body)
Xấp xỉ 222 g / 7.83 oz (Body only)
Xấp xỉ 319 g / 11.25 oz (SD card, Battery, H-H014 lens included)
Xấp xỉ 359 g / 12.66 oz (SD card, Battery, H-PS14042 lens included)
Xấp xỉ 429 g / 15.13 oz (SD card, Battery, H-FS014042 lens included) |
| Nhiệt độ hoạt động |
0 °C to 40 °C (32 °F to 104 °F) |
| Độ ẩm hoạt động |
10%RH to 80%RH |
| Software |
PHOTOfunSTUDIO 6.2 HD Edition, SILKYPIX® Developer Studio 3.1 SE, Super LoiLoScope (trial version), USB Driver |
